7 Watt T5 LED; Miniature bi-pin base; 3000K; 50000 Average rated hours; 700 Lumens; 120-277 Volt;

Image may not reflect selected features

7 Watt T5 LED; Miniature bi-pin base; 3000K; 50000 Average rated hours; 700 Lumens; 120-277 Volt; (LND1X)

7 Watt T5 LED; Miniature bi-pin base; 3000K; 50000 Average rated hours; 700 Lumens; 120-277 Volt; Type B; Ballast Bypass; Double Ended Wiring

Product Specification

Item #

LND1X

Dimensions

Width: 0.83"

Additional product details

Category

LED

Sub-Category

LED T5

Volts

120V-277V

Bulb Dimmable

Non-Dimmable

Bulb Hours

50000

Bulb Kelvin

3000K

Bulb Shape

Diameter

0.83

EA Length

0.9

Harmonized Codes

8539.52.0051

Length

20.91

Lumens

700L

Shap Carton Width

0.9

Ship Carton Height

Ship Weight

0.13

Warranty

5 Year Limited - T5 LED Bulbs - Ballast Bypass

Weight

0.21

Additional Info

Replaces F13T5/WW lamps

BAA Compliant

Ballast Bypass Direct

Ballast Bypass

Ballasting Requirements

No ballast or external driver required

Beam Spread

240

Bulb ANSI Base

Bulb Base

Miniature Bi Pin

Bulb Finish

Frost

Burning Position

Universal

Carton Cubic Feet

0.0098

Cartons Per Unit

CCT Selectable

CEC

Exempt - Base Not Regulated

CEC Terse

Lawful for sale in California

CEC Web Text

Lawful for sale

Color Temprature

Warm White

Country Of Origin

China

CRI

DLC Approved

Efficacy

100.00 LPW

Enclosed Fixture Use

Yes

Enclosure Rating

Enclosed Rated Lamp

FCC Compliant

Yes

Feature 1

MOL: 20.91 inches, MOD: 0.83 inches

Feature 2

Superior 82 CRI light quality, 700 lumens, 3000K warm white light, with a 240 degree beam spread

Feature 3

Rated for enclosed fixtures

Feature 4

Damp location rated

Feature 5

13 watt fluorescent equivalent

Feature 6

Frost finished linear bulb

Feature 7

LED energy efficient fixture

Feature 8

5 Year Limited Warranty

Flourescent Equivalent

13W

Incandescent Equivalent

50W

Installation Notes

Not for use in vapor tight fixtures. Direct wire 120-277V line voltage; Double ended wiring

Lamp Ballast Type A/B/C

Type B

Lamp End Type

Double Ended

Lamp Filament

LED

Lens

Yes

Lens Finish

Frost

Location Rating

Damp

Long Description

Satco's S11907 7 watt T5 LED Type B miniature bi-pin replaces traditional linear lamps with a no ballast, no external driver option for lasting retrofit conversion. With double ended wiring for convenience, the frosted bulb has a temperature of 3000 ke

Material

Glass

Nominal Length

NSF Approved

Yes

Operating Frequency

50/60Hz

Operating Temp

-25C (-13F) to +45C (+113F)

Pack Type

Box

Power Factor

0.9

Quantity In Pack

RoHS Compliant

Yes

Romance Copy

Satco's 7 watt T5 LED Type B miniature bi-pin replaces traditional linear lamps with a no ballast, no external driver option for lasting retrofit conversion. With double ended wiring for convenience, the frosted bulb has a temperature of 3000 kelvins a

SDS class

LED_Lamp

Shatter Proof Text

PET Coated

Short Description

7W/LED/T5/830/BP

Style

Utility

Surge Protection

Built-in-surge protection - 0.5KV

Technology

LED

Title 20 Compliant

Total Harmonic Distortion

20%

Wattage Selectable

Watts

Finish Family

Additional options that would change other selections

Call for Price

Qty:

BASE PRICE:

/ / 1

($7.95 / 1)

Add To Cart

Add To Estimate

Add To Wishlist

Save To Compare

Availability:

Manufacturer has 1107 items available.
